Glass Lined Wiped Film Evaporator

Glass lined wiped film evaporator/WFE is a kind of continuously type fully closed process equipment for evaporation concentration, desolvation, stripping, reaction, degassing and deodorization, which is widely used in pharmaceutical, domestic chemical, agrochemical, fine chemical, petrochemical, food industry and waste water processing industry. It is a new type of high efficiency evaporator which can be used for falling film evaporation under vacuum. The excellent corrosion resistance and cleanliness of the glass-lined cylinder is especially suitable for the corrosive medium in the above industries.

Glass lined WFE is a three-section vertical type pressure vessel equipment. Its construction mainly includes a glass-lined separation cylinder with a head, a jacketed glass-lined two-end flange mounted type evaporation cylinder, a jacketed glass-lined flange mounted type bottom cylinder, a glass-lined rotor assembly with PTFE wipers, a double bearing gearmotor support, a PTFE distribution plate, a PTFE or PTFE lined steel fixed plate, motorgear device, mechanical seal, heating/cooling jacket, temperature and pressure measurement device and etc.

Evaporation is considered to be a mild, safe and effective separation method. It can be used to concentrate, purify or separate molecules with poor thermal stability and related organic mixtures and compounds with low volatility, high boiling point and high viscosity. In high vacuum environment, it has the characteristics of low temperature, short material heating time and fast separation speed.

PRODUCT SPECIFICATION

MANUFACTURE PROCESS

CERTIFICATE

OUR PARTNER

VISITORS AND EXHIBITION

HIGH PERFOMANCE GALSS LINING

EXPORTS

INAPPLICATION MEDIA & OPERATING CONDITIONS FOR GLASS LINED EQUIPMENT

FAQ

1. For we can quote accurately and supply quality products, please provide technical data along with your inquiry as such:

1) Required design and working pressure, temperature of equipment

2) The corrosion performance or PH value of working medium (if have)

3) Connect flange standard

4) Power supply - Voltage, Frequency, Explosion proof and protection class according with field application

5) Equipment operating ambient - Installation site(Room/outdoor installation, heated/unheated room), class of hazardous and fire hazardous area, climatic version and category of location

2. Our MOQ is one set of each equipment.

3. Our port of loading is Qingdao seaport, P.R.China

4. Our delivery time is from 60 to 120 days after we get the 30% deposit payment and confirm the diagrams for different equipment.

5. Our product warranty time is one year from delivery.

6. Our common payment term is 30% of contract amount by T/T advanced as deposit, balance 70% by T/T or L/C at sight.

7. If your need the certificate that issue by a third party, please let us know.
